High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Großes Bild : High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Produktdetails:

Herkunftsort:	China
Markenname:	SENCAN
Zertifizierung:	CE, ISO9001
Modellnummer:	SC-TP-814

Zahlung und Versand AGB:

Min Bestellmenge:	1 Satz
Preis:	Negotiate price according to actual situation
Verpackung Informationen:	Holzkiste
Lieferzeit:	90 Tage
Zahlungsbedingungen:	T/T, L/C
Versorgungsmaterial-Fähigkeit:	2-20 Sätze

Kontakt

Ausführliche Produkt-Beschreibung

Luftdruckmesser:	SMC	Betriebsgeschwindigkeit:	Einstellbar
Betriebsmethode:	Drehteller/mechanischer	Effizienzverhältnis:	Mehr als 95%
Operations-Person:	1 Person	Material:	Edelstahl
Produktleistung:	220V	Frequenz:	50/60Hz
Montagekapazität:	4500-12000 pro Stunde	Operator:	Einzel
Zufriedenstellende Rate:	Ungefähr 99%	Anwendbare Kappen:	Euro-Kapital
Betriebsmodus:	Halbautomatisch	Mechanismus:	Servo
Hervorheben:	Fast and Accurate Euro Cap Assembly Machine , 99% Satisfactory Rate Infusion Cap Assembly Machine , 4500-12000 per/hour Automatic Cap Assembly Machine

High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly

Product Features

Designed for automatic assembly of easy peel foil caps for IV infusion soft bags and bottles
Constructed with stainless steel and aluminum alloy materials, compliant with GMP standards
Independent driving source for each workstation, facilitating easy maintenance
Product-contact surfaces polished for optimal product protection
Automated foil cutting and welding process
Integrated check function after each assembly step to ensure product quality
PLC control system with user-friendly interface, requiring minimal operator training
Servo motor + indexing drive power system for high precision assembly and qualification rates
Pneumatic power system reduces maintenance time and technical requirements
Fully customizable to meet specific product specifications, capacity, and production demands

Technical Specifications

Applicable Products	Peel seal foil caps, foil seal closures and lids
Production Speed	1500-8500pcs/hr (customizable to customer requirements)
Qualified Product Rate	Above 99%
Operation Rate	Above 95%
Power Source	AC380V, 50Hz, 4kw/hr
Dimensions	Varies according to production speed requirements
Weight	Approximately 2000kg
Operator Requirements	3 sets/2 persons, recommended 1 set/person
